ターミナルブロックで3レベルプッシュ

原産地：中国
ブランド名：WKDQ / WONKEDQ
認定：CE/ROHS/CQC/ISO 9001
モデル番号：PT2.5-3L
パッケージの詳細：ボックス
配送時間：2〜7日
支払い条件：T/T、PayPal、Western Unionなど

モデル:JPT2.5-3L

お問い合わせを送信

製品説明

Three layer direct insertion terminal block: VO grade flame-retardant PA66 material, CE/Rohs/CQC certification. Tool free direct insertion compatible with multiple wire types, compact structure compatible with NS35 rails, built-in potential bridge supporting high-density wiring, flexible expansion accessories, industrial grade safety flame retardant and space optimization integrated design.

Model Number	JPT2.5-3L
Color	Grey,Blue, other color can be customized
Length/Wide/Height (mm)	103 / 56.4 / 5.2 mm
Connection method	Push-in connection
Material	Flame resistant Nylon PA66 V0
Rated Voltage/Current	500V/22A
Cross section, solid/soft Cable	0.14-4mm²/0.14-2.5mm²
Conductor Size	26-12AWG
Mounting Type	DIN Rail NS 35
Standard	IEC 60947-7-1
LOGO	WonkeDQ, WKDQ, LOGO can be customized
Packing Detail	10.23g/pc, 50PCS/BOX
Certification	CE/RoHS/CQC/ISO 9001
